Set number: 989

  • Reticulofenestra hesslandii 938 5 1
    5µm
Reticulofenestra hesslandii, Middle Miocene, Malta

Set number: 1061

  • Reticulofenestra hesslandii 995 3 1
    5µm
Reticulofenestra hesslandii, Late Miocene, Antalya-Manavgat Road, Turkey

Set number: 988

  • Reticulofenestra hesslandii 26423 1
  • Reticulofenestra hesslandii 26426 2
  • Reticulofenestra hesslandii 26427 3
  • Reticulofenestra hesslandii 26431 4
  • Reticulofenestra hesslandii 26424 5
  • Reticulofenestra hesslandii 26425 6
  • Reticulofenestra hesslandii 26428 7
  • Reticulofenestra hesslandii 26435 8
    10µm
Reticulofenestra hesslandii, Late Miocene, DSDP Leg 25, Site 242, Mozambique Channel (Davie Ridge), Indian Ocean

Set number: 987

  • Reticulofenestra hesslandii 19501 1
  • Reticulofenestra hesslandii 19503 2
  • Reticulofenestra hesslandii 19505 3
  • Reticulofenestra hesslandii 19508 4
  • Reticulofenestra hesslandii 19502 5
  • Reticulofenestra hesslandii 19504 6
  • Reticulofenestra hesslandii 19506 7
  • Reticulofenestra hesslandii 19511 8
    10µm
Reticulofenestra hesslandii, Late Miocene, Gulf of Mexico

Set number: 986

  • Reticulofenestra hesslandii 1485 1
  • Reticulofenestra hesslandii 1484 2
  • Reticulofenestra hesslandii 1482 3
  • Reticulofenestra hesslandii 1483 4
    10µm
Reticulofenestra hesslandii, Middle Miocene, Malta

Set number: 985

  • Reticulofenestra hesslandii 1447 1
  • Reticulofenestra hesslandii 1446 2
  • Reticulofenestra hesslandii 1445 3
  • Reticulofenestra hesslandii 1444 4
    10µm
Reticulofenestra hesslandii, Middle Miocene, Malta
Final Epithet
Reticulofenestra hesslandii (Haq, 1966) Roth, 1970
Basionym

Ericsonia hesslandii Haq, 1966

Synonyms

Reticulofenestra haqii Backman, 1978

Description

Medium size [4.0-8.0µm] elliptical species of Reiculofenestra Hay, Mohler & Wade (1966) with a narrow circular central opening distally but narrow elliptical central opening proximally. The size of the opening and the width of the tube cycle varies greatly.

Remarks

Reticulofenestra hesslandii differs from Reiculofenestra gelida (Geitzenauer in Geitzenauer & Huddlestun, 1972) Backman (1978) and Reiculofenestra clemencesellayae Varol, in prep. by being smaller [4.0-8.0µm] whilst the later species are greater than 8.0µm. It is distinguished from Reiculofenestra asafis Varol, in prep. by having a larger, well-defined circular central opening.

References

Backman, J., (1978): Late Miocene - Early Pliocene nannofossil biochronology and biogeography in the Vera Basin, SE Spain. - Stockholm Contributions in Geology. 32: 93-114.

Geitzenauer, K. R. & Huddlestun, P., (1972): An upper-Pliocene-Pleistocene calcareous nannoplankton flora from a subantarctic Pacific deep-sea core. - Micropaleontology. 18(4): 405-409.

Haq, B. U., (1966): Electron microscope studies on some upper Eocene calcareous nannoplankton from Syria. - Stockholm Contributions in Geology. 15: 23-37.

Hay, W. W., Mohler, H. P. & Wade, M. E., (1966): Calcareous nannofossils from Nal'chik (northwest Caucasus). - Eclogae Geologicae Helvetiae. 59: 379-399.

Roth, P. H., (1970): Oligocene calcareous nannoplankton biostratigraphy. - Eclogae Geologicae Helvetiae. 63: 799-881.
